Dinero Bounty Details

• Until TVL > $5,000,000
  • Max Critical: $500,000 in ETH
  • High Severity: $30,000 in ETH
• Once TVL > $5,000,000
  • Max Critical: 10% of impacted TVL, up to $2,000,000 in ETH
  • High severity: $50,000 in ETH
• Join C4 Discord to register
• Submit findings using the C4 form
• Read our Code4rena Blue guidelines for more details

❗ Note for participants: The sponsor's repo, scope definition, and contents herein are all subject to change.

Publicly Known Issues

• All issues submitted via wardens and the Blue Team during this Code4rena Blue engagement will be added to this project list weekly.

• Centralization Risks: Some methods (specially upgradeAndCall) are only accessible by the Dinero DAO multisig, which is the sole owner of the contracts. This is acceptable as the multisig is controlled by the Dinero DAO, which is a decentralized organization. These methods would only be used for emergency purposes, such as in the event of a critical bug or a hack.

• Pirex ETH Liquidity: While brandedETH is immediately minted on the L2 network, the actual ETH is batched and sent over the native bridge. This means there is a period where pxETH is minted, but the ETH is not yet available in the PirexETH contract. Although users should receive the full withdrawal in pxETH at all times, attempts to redeem pxETH for ETH before the ETH is available may fail. This will depend on the redemption size and the amount of ETH deposited into the PirexETH validators.

• Branded LST Yield Dilution: brandedETH users' balances are adjusted according to the yield accrued in the apxETH vault, which is determined by ETH rewards from PirexETH validators that increase the vault's assetsPerShare ratio. From the perspective of brandedETH users, yield can start accruing immediately after a deposit through a rebase. However, since the ETH deposited direclty on L2 is not immediately available to stake due to the native bridge delay, the yield gets diluted. This dilution issue is constrained to brandedETH users because the deposit into the apxETH vault is delayed until ETH reaches L1, and the assetsPerShare ratio synced between L1 and L2 considers balances in apxETH and pxETH held by the lockbox.

• Out of Gas During Withdrawal: Pending sync batches amounts are consumed during the withdrawal through the syncIndexPendingAmount array. If there are many pending syncs, A large withdrawal would cause iterating over many items of the array, which would cost much gas, and could block users from withdrawing due to out-of-gas error. The likelihood of this scenario happening is directly correlated with the minSyncAmount set by the protocol team. The protocol team should set the minSyncAmount and monitor L2 deposits to ensure the system can handle large withdrawal amounts.

• Oracle Dependency: Users rely on the L2ExchangeRateProvider contract to fetch the assetsPerShare ratio of the AutoPxEth vault during deposits. If the oracle fails to provide accurate data, it could severely impact both users and the protocol. Potential consequences include discrepancies in asset valuation or unbacked Branded LST tokens. The protocol team must monitor the oracle closely to ensure its accuracy and reliability, as failures could compromise the system's integrity and user trust.

• Delayed Rebase: If the rebase is not called for a long time, the assetsPerShare ratio on L2 will be outdated. This could lead to a discrepancy between the actual AutoPxEth vault yield and the yield accrued by the brandedETH holders, affecting negatively users' yield. The protocol team should monitor the rebase calls and ensure that they are called regularly and close to Harvest events.

• PirexETH Deposit Fee Increase: Increase in the PirexETH deposit fee, while there are ETH pending deposits in the native bridge, could lead to unbacked pxETH tokens. The tokens can be minted if the deposit fee (on PirexEth) is increased between the delivery of fast and slow sync messages. This would happen because the amount of pxETH minted after the fast message is received would be higher than the amount of pxETH burned when the slow message is received. While PirexETH team does not plan to increase the deposit fee, the protocol team should monitor the deposit fee and ensure that it is not increased while there are pending deposits in the native bridge.

• Slippage Protection on Non Native Deposits: Users must carefully set the minAmountOut parameter when depositing WETH on L2. Since Stargate pools can be manipulated, the actual amountOut could be significantly lower than amountIn without proper slippage protection.

Note: We have acknowledged all findings in referenced Audits and have either fixed them or have mitigated them. These functions are required for the protocol to work as intended.

Branded LST Overview

The Branded LST is an extension of the PirexETH protocol on a Layer 2 (L2) ecosystem. Instead of holding the AutoPxEth vault shares on Layer 1 (L1), users can hold the liquid staking token (LST) on L2 and benefit from the apxETH yield.

The LST can be obtained by performing a deposit on either L1 or L2. On L1, the accepted tokens include Ether, pxETH, and apxETH, while on L2, whitelisted token such as Ether and WETH are accepted. Unlike deposits, the withdrawals can be initiated exclusively from the L2 side. In exchange for the LST, users receive the same amount of pxETH, in a 1:1 ratio. The pxETH can be redeemed for Ether at any time, and the redemption rate is always 1:1 on Pirex ETH protocol.

Tokenization

• brandedLST is a rebasing Ethereum liquid staking token native to a Layer 2 ecosystem. Branded ETH benefits from apxETH yield and maintains an 1:1 redemption rate with pxETH. Rebases are permissionless and triggered on mainnet to adjust the assetsPerShare ratio on L2.

• wBrandedLST is a wrapped version of brandedLST that can be used in DeFi applications. It is minted by depositing brandedLST into the WrappedLiquidStakedToken contract. The minted wBrandedLST can be used in DeFi applications, such as lending, borrowing, and trading.

• Branded LST OFT is the 1:1 representation of wBrandedLST on another L2 chain. It is minted by depositing wBrandedLST into the OFTLockbox contract. The minted Branded LST OFT can be used in DeFi applications on the other L2 chain.

Architecture

The following sections delve into the system’s components and their interactions. The diagram below showcases a high-level view of the system’s architecture.

<img width="100%" alt="image" src="https://github.com/user-attachments/assets/cf37d8d8-1660-4ac5-9a74-04b70e85ba71">

Fig. 1: L2 brandedETH architecture

Deposit

Layer 1 deposits are facilitated through the LiquidStakingTokenLockbox contract. The Lockbox is responsible for handling the Ether, pxETH, and apxETH token deposits into the PirexETH protocol. Communication between L1 and L2 is done with the LayerZero messaging system. During the deposit, the Lockbox sends the LayerZero message to the L2 chain containing the deposit amount, current assetsPerShare, receiver address and the lastest fully synced batches. The LiquidStakingToken contract that receives this message on L2 can use the provided information to mint an appropriate amount of LST shares as well as perform a rebase using the new assetsPerShare ratio from the AutoPxEth vault.

<img width="100%" alt="image" src="https://github.com/user-attachments/assets/1648793f-6909-48d5-809c-c009c24899e4">

Fig. 2: Mainnet Deposit flow

Layer 2 deposits are facilitated through the LiquidStakingToken contract using the logic of L2SyncPool contract. Since the L2 Ether cannot immediately be used for staking in the PirexETH protocol, it must be first bridged to the L1 Ether via the native Layer 2 bridge. The L2 deposits are batched together and sent to L1 during the cross-chain syncing process. The synchronization mechanism itself is explained in greater detail in the Synchronization section. Once Ether is released from the L1 native bridge, it is deposited into the PirexETH protocol to start the Ether staking process. The validator staking rewards generate the yield for the LST and apxETH token holders.

<img width="70%" alt="image" src="https://github.com/user-attachments/assets/59d7154c-56d0-4894-94e4-a6045a6a2733">

Fig. 3: Layer 2 Deposit flow

Side Layer 2 deposits are facilitated through the OFTMinter contract. The OFTMinter contract is responsible for handling the deposits of LiquidStakingTokens between Layer 2s. The OFTMinter contract receives a deposit and fowards to the Layer 2. After receiving tha message back from the base Layer 2 the OFTs tokens are minted on the destination chain.

<img width="70%" alt="image" src="https://github.com/user-attachments/assets/353653f7-2874-4468-b056-5e4f362a024d">

Fig. 4: Side Layer 2 Deposit flow

Rebase

Whenever new rewards are distributed into the AutoPxEth vault through the Harvest process, the price of an individual apxETH share increases. Since LST shares are L2 representations of the apxETH shares, this share price increase must also be reflected on the Layer 2 chain. The rebase mechanism informs the L2 about the newest assetsPerShare ratio from the AutoPxEth vault. The current L1 share price is used to update the internal accounting on L2. Similarly to the synchronization mechanism, calling LiquidStakingTokenLockbox.rebase(...) is permissionless but will be regularly called by the Keeper.

<img width="85%" alt="image" src="https://github.com/user-attachments/assets/77cc6684-eba4-4513-bb34-079b97de5f0d">

Fig. 4: Rebase flow

Synchronization

The L1 chain is unaware of the user deposits on L2 until the two chains are synchronized. The syncing process can be done by calling the LiquidStakingToken.sync(...) function. To keep the chain states up to date, the off-chain keeper will trigger the synchronization regularly. This action is permissionless, meaning that anyone can call the sync(...) function once a certain threshold of deposits is reached (minSyncAmount).
The synchronization mechanism is split into two parts: the slow sync and the fast sync.

<img width="100%" alt="image" src="https://github.com/user-attachments/assets/3f3f7185-635b-460c-96f5-c1e1d3393bd4">

Fig. 5: Sync flow

The slow sync process sends the native Layer 2 Ether or WETH to Layer 1 over the native bridge. Due to the nature of optimistic rollups and the design of the fault-proof system, this process can take up to 7 days to finalize (for OP Stack-based rollups). The message won’t be relayed during that time, and the Ether won’t be released on L1. To mitigate this limitation the message is sent via LayerZero omnichain messaging protocol to inform the L1 about the deposit on L2, this process is called fast sync.

The fast sync The LiquidStakingTokenLockbox contract receives this message and mints pxETH tokens in anticipation of the Ether that is yet to be released from the bridge. The newly minted pxETH tokens stay in the contract, where they wait for the slow sync process to finish. If, during the waiting period, users request withdrawals on L2, whenever possible, they will be provided with the pxETH tokens from the Lockbox first instead of withdrawing funds from the AutoPxEth vault. The fast sync mechanism enables immediate liquidity for the L2 users without affecting the existing AutoPxEth deposits before the actual Ether arrives from the bridge.

Withdraw

Unlike deposits, withdrawals can only be initiated on the L2 side. Users can call the LiquidStakingToken.withdraw(...) function and specify the amount of assets that they want to withdraw. Their LST shares will be burned on L2, and a withdrawal message will be sent to L1 via LayerZero. Once the LiquidStakingTokenLockbox contract receives the message, it will transfer the pxETH tokens to the user on L1. As mentioned in the previous section, the Lockbox will first attempt to use all the pxETH that it currently holds, and only after that will it start withdrawing additional pxETH tokens from the vault.

<img width="100%" alt="image" src="https://github.com/user-attachments/assets/c960316c-1253-4e85-a611-e35573e20ab2">

Fig. 6: Withdraw flow

Links

• Previous audits:
  • Spearbit - PirexETH (@spearbitdao)
  • Pashov - PirexETH (@pashovkrum)
• Documentation:
  • PirexETH & Dinero Documentation
  • PirexETH Whitepaper
  • Dinero Litepaper
• Website: https://dinero.xyz
• Twitter: (@dinero_xyz)
• Discord: https://discord.gg/dineroxyz

Scope

This is the complete list of what's in scope for this contest:

This is a list of mainnet contract deployments:
Plume Staked Ether (pETH)

Ink Staked Ether (iETH)

ZKSync Staked Ether (zkETH)

Flare Staked Ether (flrETH)

Berachain Staked Ether (beraETH)

Orbit Staked Ether (orbETH)

Out of scope

Contracts:

• BridgeQuoter.sol

Vendor Libraries:

• chainlink
• solidty-cborutils
• layerzero
• layerzero-upgradeable
• zksync

Additional Context

• Trusted Roles

  • DEFAULT_ADMIN_ROLE: Set keeper role in the Oracle contract
  • KEEPER_ROLE: Set Oracle answer
  • SYNC_KEEPER: Execute sync on Layer 2
  • OWNER: Set OApp delegate, peers and update key parameters
  • DELEGATE: Set OApp configuration

• EIP Specifications:

  • DineroERC20RebaseUpgradeable: Should comply with ERC-20 standard
  • WrappedLiquidStakedToken: Should comply with ERC-20 standard

• In the event of DOS, we would consider a finding to be valid if it is reproducible for a minimum duration of 4 hours.

Main invariants

• Setting and updating contract addresses (wLST, peers etc) which are controlled by the OWNER
• brandedLST.totalSupply should not be greater than pxETH equivalent assets in the lockbox (under collateralization)
• totalShares
• totalStaked
• unsyncedPendingDeposit
• syncedPendingDeposit
• pendingDeposit
• avgAssetsPerShare

Scoping Details

• If you have a public code repo, please share it here: https://github.com/dinero-protocol/pirex-eth-contracts
• How many contracts are in scope?: 27
• Total SLoC for these contracts?: 2776
• How many external imports are there?: 88
• How many separate interfaces and struct definitions are there for the contracts within scope?: 16 interfaces & 20 structs
• Does most of your code generally use composition or inheritance?: Yes, inheritance
• How many external calls?: 1 - Native bridge call (Arbitrum, Optimism, ZKSync), 2 - LayerZero call (send and quote), 1 Startgate bridge call (sendToken)
• What is the overall line coverage percentage provided by your tests?: 99.8%
• Is this an upgrade of an existing system?: No
• Check all that apply (e.g. timelock, NFT, AMM, ERC20, rollups, etc.): ERC-20
• Is there a need to understand a separate part of the codebase / get context in order to audit this part of the protocol?:
• Please describe required context:
• Does it use an oracle?: Yes - Internal oracle to fetch the assetsPerShare ratio
• Does it use a side-chain?: Yes
• Describe any specific areas you would like addressed:

Miscellaneous

Employees of Dinero Protocol, and employees' family members are ineligible for bounties.
